Product Description

The MONISMS Dante Audio Amplifier is a compact power amplifier module that drives small 4-8Ω speakers [Ceiling Speaker, In-wall Speaker, Pendant Speaker Column Speaker etc.] The MONISMS Dante Amplifier has two outputs,  each with 30W of power into an 4-8Ω load, This makes the module ideal for powering small areas consisting of only a few low power speakers.
The module's audio input is via an Ethernet audio network, allowing the use of the DANTE/ AES67 audio network protocol.
MNS-AMP60XXA-2D MAX power 60W,  Powered  by external 19VDC.
Dante Audio Amplifier  can be mounted on a DIN rail or screwed onto a panel or wall for easy installation in a remote closet near the speaker area.

[Model:MNS-AMP6011A-2D] 1 Channel, 60W Out, [1 Pair Speaker Terminals].
[Model:MNS-AMP6022A-2D] 2 Channels, 2*30W, [2 Pairs Speaker Terminals].

Features:
Supports sample rates up to 96kHz via Audinate UXT Ultimo chipset. This chipset supports both AES67 and SMPTE 2110.
Powered by external 19V.
RJ45 Connection for Audio from POE+ Ethernet.
2*RJ45, [Two RJ45 gigabit RJ45 ports to support daisy chaining] With 1000M switch for feed-through output.
Dante Domain Manager and AES67 Support.
